Genie · Diesel articulating boom lift
Genie Z-34/22 IC
Diesel articulating boom lift rental · working height 12.54 m · capacity 227 kg · 4×4 drive
- Working height
- 12.54m
- Capacity
- 227kg
- Horizontal outreach
- 6.78m
- Width
- 1.85m
- Weight
- 4,994kg
The Genie Z-34/22 IC diesel articulating boom lift from the RK Rental fleet gives you 12.54 m of working height, 6.78 m of horizontal outreach and 227 kg of capacity in a compact 4×4 machine. The articulating boom clears obstacles at a height of 4.60 m, so you can position the basket over a canopy, a fence or a lower roof. We deliver to Bydgoszcz, Toruń, Włocławek, Poznań, Świecie and anywhere in Poland.
Genie
Rental
Genie Z-34/22 IC: from PLN 160 + VAT per day
The lowest rate applies to rentals of more than 14 days; for shorter rentals the daily rate is higher. We arrange delivery across Poland.
See the price list: rates for 1–3, 7 and 14 daysAsk about availability and price Prefer to buy? Genie Z-34/22 IC, newBuy the rented machine: will it prove itself on the job? You can buy it from us, with the possibility of deducting part of the rental costs from the price of the machine.What are the specifications of the Genie Z-34/22 IC?
- Working height
- 12.54 m
- Platform height
- 10.54 m
- Capacity
- 227 kg
- Horizontal outreach
- 6.78 m
- Platform occupants
- 2
- Unladen weight
- 4,994 kg
- Power source
- Diesel
- Engine type
- Diesel
- Drive
- 4WD
- Tyres
- Rough terrain
- Intended use
- Outdoor
- Up-and-over height
- 4.60 m
- Jib length
- 1.22 m
- Drive speed (stowed position)
- 4.8 km/h
- Drive speed (platform raised)
- 1.1 km/h
- Tyre contact pressure
- 310 kPa
- Floor pressure (tyres)
- 10.58 kPa
- Vibration (platform)
- 2.5 m/s²
- Fuel tank
- 34 L
- Hydraulic tank capacity
- 71.9 L
What are the dimensions of the Genie Z-34/22 IC?
- APlatform length
- 0.76 m
- BPlatform width
- 1.42 m
- CHeight (stowed position)
- 2.06 m
- DLength (stowed position)
- 5.66 m
- EStorage height
- 2.29 m
- FStorage length
- 4.11 m
- GMachine width
- 1.85 m
- HWheelbase
- 1.88 m
- IGround clearance under chassis
- 0.17 m
What is the Genie Z-34/22 IC used for?
The Genie Z-34/22 IC is a rough terrain articulating cherry picker with a combustion engine, four-wheel drive and 25 × 42 cm rough terrain tyres. The 1.42 × 0.76 m platform holds 2 people with tools, and the 1.22 m jib lets you position the basket precisely at a gutter, beam or light fitting without repositioning the whole machine.
Zero turntable tail swing means that when the upper structure rotates it does not extend beyond the chassis footprint, so the machine can be slewed right next to a wall or within a narrow strip of road. When stowed, the lift travels at up to 4.8 km/h, and with the platform raised at 1.1 km/h. Ground clearance under the chassis is 0.17 m.
Stowed dimensions are 5.66 m in length, 1.85 m in width and 2.06 m in height, with an unladen weight of 4,994 kg, making it one of the lighter rough terrain articulating booms, easy to transport and putting less load on the ground (floor pressure 10.58 kPa). The combustion engine requires good ventilation when working in enclosed buildings.
- Façades and sheet metal flashings
- Installing gutters and rainwater systems
- Work over canopies and fences
- Outdoor lighting and CCTV
- Tree pruning and municipal work
- Servicing halls from the outside
What does renting the Genie Z-34/22 IC include?
- We arrange transportDelivery and collection of the machine: Bydgoszcz, Toruń, Poznań and all over Poland.
- Current UDT inspectionThe machine arrives after inspection, with a valid UDT inspection (UDT is the Polish Office of Technical Inspection) and full documentation.
- Mobile serviceRepair on site at the customer's location, on the construction site, in the hall or warehouse; if needed, a replacement machine from a fleet of over 250 machines.
