JLG · Electric articulating boom lift
JLG M600JP Bi-Energy
Electric articulating boom lift rental · working height 20.39 m · capacity 230 kg · 4×4 drive
- Working height
- 20.39m
- Capacity
- 230kg
- Horizontal outreach
- 13.54m
- Width
- 2.42m
- Weight
- 8,015kg
The JLG M600JP electric articulating boom lift, available for rental, provides 20.39 m of working height, 13.54 m of horizontal outreach and 230 kg of capacity: a cherry picker for work high under the roofs of large halls, atriums and industrial buildings. It stands out for its hybrid power (48 V batteries recharged by a 5 kW generator), 4WD, non-marking tyres and a 1.24 m jib with 180° horizontal rotation. We deliver it to Bydgoszcz, Toruń, Poznań and anywhere in Poland.
JLG
Rental
JLG M600JP Bi-Energy: from PLN 350 + VAT per day
The lowest rate applies to rentals of more than 14 days; for shorter rentals the daily rate is higher. We arrange delivery across Poland.
See the price list: rates for 1–3, 7 and 14 daysAsk about availability and price Buy the rented machine: will it prove itself on the job? You can buy it from us, with the possibility of deducting part of the rental costs from the price of the machine.What are the specifications of the JLG M600JP Bi-Energy?
- Working height
- 20.39 m
- Platform height
- 18.39 m
- Capacity
- 230 kg
- Horizontal outreach
- 13.54 m
- Unladen weight
- 8,015 kg
- Power source
- Hybrid (Bi-Energy)
- Drive
- 4WD
- Tyres
- Non-marking
- Intended use
- Indoor
- Working outreach (with jib)
- 14.19 m
- Turntable rotation
- 400° (non-continuous)
- Platform rotation (hydraulic)
- 180°
- Jib length
- 1.24 m
- Jib vertical articulation
- 145° (+89° / −56°)
- Jib horizontal rotation (JibPLUS)
- 180°
- Inside turning radius
- 1.22 m
- Outside turning radius
- 4.64 m
- Axle oscillation
- 0.20 m
- Drive speed
- 4.8 km/h
- Gradeability
- 30%
What are the dimensions of the JLG M600JP Bi-Energy?
- APlatform dimensions (W × L)
- 0.76 × 1.83 m
- BOverall width
- 2.42 m
- CTail swing (in working position)
- 1.23 m
- DStowed height (transport)
- 2.54 m
- EStowed length (transport)
- 10.15 m
- FWheelbase
- 2.74 m
- GGround clearance
- 0.30 m
What is the JLG M600JP Bi-Energy used for?
The JLG M600JP is a large aerial work platform with an articulating boom that combines the reach typical of rough terrain machines with quiet battery operation. Eight 6 V batteries with a capacity of 415 Ah power two electric drive motors and the hydraulic pump, while an automatic Kubota 5 kW generator recharges them during work. As a result, the cherry picker can work longer away from a power socket, with less downtime for charging.
Non-marking tyres protect industrial floors, while 4WD and 30% gradeability make it easier to drive up ramps. Inside buildings it is best to work in battery mode and to run the generator only where ventilation allows. When planning access, take into account the 2.42 m width, 2.54 m stowed height, 10.15 m transport length and 8,015 kg weight; the floor must withstand a pressure of up to 3.9 kg/cm².
When choosing a machine in the approximately 20 m class, look at the jib: the 1.24 m jib works through a 145° range (+89° / −56°) and rotates 180° horizontally (JibPLUS), which makes it easier to reach installations between girders. The 0.76 × 1.83 m platform holds tools and materials, and the turret rotates through 400°. In the working position the rear of the turret swings out by 1.23 m, and this space must be kept clear during rotation.
- Installing services under hall roofs
- Overhead crane and lighting maintenance
- Work in atriums and halls
- Sprinkler and ventilation installations
- Roof structures from the inside
- Work on clean floors
What does renting the JLG M600JP Bi-Energy include?
- We arrange transportDelivery and collection of the machine: Bydgoszcz, Toruń, Poznań and all over Poland.
- Current UDT inspectionThe machine arrives after inspection, with a valid UDT inspection (UDT is the Polish Office of Technical Inspection) and full documentation.
- Mobile serviceRepair on site at the customer's location, on the construction site, in the hall or warehouse; if needed, a replacement machine from a fleet of over 250 machines.
