JLG · Electric scissor lift
JLG 1930ES
Electric scissor lift rental · working height 7.72 m · capacity 230 kg
- Working height
- 7.72m
- Capacity
- 230kg
- Platform height
- 5.72m
- Width
- 0.76m
- Weight
- 1,565kg
Renting the JLG 1930ES electric scissor lift gives you 7.72 m of working height and 230 kg of capacity with a width of 0.76 m, making it a manoeuvrable scissor lift for service and installation work in industrial buildings and offices. It stands out for driving at the full platform height of 5.72 m and for approval for outdoor use with one person on the platform. We deliver this machine from the RK Rental fleet in Bydgoszcz, Toruń, Poznań and anywhere in Poland.
JLG
Rental
JLG 1930ES: from PLN 80 + VAT per day
The lowest rate applies to rentals of more than 14 days; for shorter rentals the daily rate is higher. We arrange delivery across Poland.
See the price list: rates for 1–3, 7 and 14 daysAsk about availability and price Buy the rented machine: will it prove itself on the job? You can buy it from us, with the possibility of deducting part of the rental costs from the price of the machine.What are the specifications of the JLG 1930ES?
- Working height
- 7.72 m
- Platform height
- 5.72 m
- Capacity
- 230 kg
- Outdoor capacity (1 person)
- 120 kg
- Capacity on deck extension
- 120 kg
- Unladen weight
- 1,565 kg
- Power source
- Electric
- Maximum drive height
- 5.72 m (drivable at full height)
- Platform occupants (indoor / outdoor)
- 2 / 1
- Turning radius (inside / outside)
- 0 m / 1.75 m
- Drive speed (stowed)
- 4.8 km/h
- Drive speed (raised)
- 0.8 km/h
- Lifting / lowering time
- 20 / 30 s
- Gradeability
- 25%
What are the dimensions of the JLG 1930ES?
- AStowed height (guardrails up)
- 1.98 m
- BPlatform guardrail height
- 1.10 m
- CStowed height (guardrails folded)
- 1.59 m
- DPlatform dimensions (W × L)
- 0.76 × 1.87 m
- EDeck extension
- 0.90 m
- FOverall width
- 0.76 m
- GOverall length
- 1.87 m
- HWheelbase
- 1.60 m
- IGround clearance
- 0.09 m
What is the JLG 1930ES used for?
The JLG 1930ES is a compact electric MEWP for everyday work at height in enclosed buildings: replacing light fittings, running cables, and installing sensors and ducts. The platform is 0.76 m wide and 1.87 m long, and the 0.90 m deck extension lengthens it to 2.77 m. Folding 1.10 m guardrails make transport and passing under low obstacles easier.
An overall width of 0.76 m lets it pass through standard doors, and the stowed height drops from 1.98 m to 1.59 m with the guardrails folded. The unladen weight of 1,565 kg and the maximum ground pressure of 8.73 kg/cm² are worth comparing with the load-bearing capacity of the floor or floor slab. A zero inner turning radius (1.75 m outer) makes manoeuvring between racking, machinery and production workstations easier.
This scissor lift's strengths include a drive speed of 4.8 km/h in the stowed position, which shortens journeys across large halls, and the ability to drive with the platform raised to 5.72 m. Power comes from four 6 V, 220 Ah batteries, charged from the mains by an automatic 20 A charger. Indoors, 2 people work on the platform, outdoors 1 person; the machine climbs gradients of 25%.
- Replacing light fittings
- Running cable routes
- Installing sprinkler systems
- Servicing in production halls
- Work under canopies and roofed areas
What does renting the JLG 1930ES include?
- We arrange transportDelivery and collection of the machine: Bydgoszcz, Toruń, Poznań and all over Poland.
- Current UDT inspectionThe machine arrives after inspection, with a valid UDT inspection (UDT is the Polish Office of Technical Inspection) and full documentation.
- Mobile serviceRepair on site at the customer's location, on the construction site, in the hall or warehouse; if needed, a replacement machine from a fleet of over 250 machines.
