Haulotte · Diesel scissor lift
Haulotte Compact 10 DX
Diesel scissor lift rental · working height 10.28 m · capacity 565 kg · 4×4 drive
- Working height
- 10.28m
- Capacity
- 565kg
- Platform height
- 8.28m
- Width
- 1.78m
- Weight
- 3,350kg
Renting the Haulotte Compact 10 DX diesel scissor lift gives you 10.28 m of working height, 565 kg of capacity and a width of 1.78 m. It is a rough terrain scissor lift for construction sites that combines a compact build with a roomy platform. Its key features are 4×4 drive, self-levelling outriggers, climbing gradients of up to 40% and driving with the platform raised up to 8.15 m. We deliver the machine to Bydgoszcz, Toruń, Poznań and anywhere in Poland.
Haulotte
Rental
Haulotte Compact 10 DX: from PLN 150 + VAT per day
The lowest rate applies to rentals of more than 14 days; for shorter rentals the daily rate is higher. We arrange delivery across Poland.
See the price list: rates for 1–3, 7 and 14 daysAsk about availability and price Prefer to buy? Haulotte Compact 10 DX, newBuy the rented machine: will it prove itself on the job? You can buy it from us, with the possibility of deducting part of the rental costs from the price of the machine.What are the specifications of the Haulotte Compact 10 DX?
- Working height
- 10.28 m
- Platform height
- 8.28 m
- Capacity
- 565 kg
- Platform occupants
- 3
- Deck extension
- 1.2 m
- Unladen weight
- 3,350 kg
- Power source
- Diesel
- Engine type
- Diesel
- Drive
- 4WD
- Tyres
- Rough terrain
- Intended use
- Outdoor
- Stabilising outriggers
- Yes (self-levelling)
- Number of extensions
- 1
- Extension length
- 1.2 m
- Extended platform dimensions
- 3.7 x 1.45 m
- Stowed height
- 1.59 m
- Transport height (with guardrails)
- 2.44 m
- Drive speed
- 0.6 - 5.5 km/h
- Drivable at maximum height up to
- 8.15 m
- Maximum gradeability
- 40%
What are the dimensions of the Haulotte Compact 10 DX?
- APlatform length
- 2.45 m
- Platform length (extended)
- 3.7 m
- CPlatform width
- 1.45 m
- FWidth
- 1.78 m
- GLength
- 3.17 m
- HWheelbase
- 1.84 m
- IGround clearance
- 28 cm
What is the Haulotte Compact 10 DX used for?
The Haulotte Compact 10 DX is a diesel rough terrain scissor lift with an 18.5 kW Kubota engine that meets the Stage V emission standard. The 2.45 × 1.45 m platform extends to 3.7 m with a 1.2 m deck extension, and the 565 kg capacity allows three people to work at height with tools and materials. The machine performs well on façades, roofs and structures on construction sites.
4WD, rough terrain tyres and 28 cm of ground clearance make it easier to move over soil and unpaved access roads, and self-levelling outriggers stabilise the lift before work begins. Driving is also possible with the platform raised, up to a height of 8.15 m. An outer turning radius of 3.5 m and a wheelbase of 1.84 m allow you to manoeuvre between scaffolding and material storage areas.
When choosing, pay attention to the height: stowed, the machine is 1.59 m high, and the transport height with guardrails is 2.44 m; the unladen weight is 3,350 kg. In the 10-metre MEWP class, the Compact 10 DX combines rough terrain capability with a compact chassis. With its combustion engine, it works best outdoors or in well-ventilated buildings under construction.
- Ventilated façade installation
- Roofing work and gutters
- Steel structure erection
- Construction sites with unpaved access
- Window installation
What does renting the Haulotte Compact 10 DX include?
- We arrange transportDelivery and collection of the machine: Bydgoszcz, Toruń, Poznań and all over Poland.
- Current UDT inspectionThe machine arrives after inspection, with a valid UDT inspection (UDT is the Polish Office of Technical Inspection) and full documentation.
- Mobile serviceRepair on site at the customer's location, on the construction site, in the hall or warehouse; if needed, a replacement machine from a fleet of over 250 machines.
