Manitou · Electric articulating boom lift
Manitou 150 AETJ-C
Electric articulating boom lift rental · working height 15 m · capacity 200 kg
- Working height
- 15m
- Capacity
- 200kg
- Horizontal outreach
- 7.6m
- Width
- 1.5m
- Weight
- 6,700kg
Renting the Manitou 150 AETJ-C electric articulating boom lift gives you 15 m of working height, 7.6 m of horizontal outreach and 200 kg basket capacity with a width of only 1.5 m and an almost zero counterweight overhang (0.12 m beyond the outline when the turret rotates). The 1.26 m jib with ±65° movement lets you position the basket precisely over an obstacle. We deliver the machine to Bydgoszcz, Toruń, Poznań and anywhere in Poland.
Manitou
Rental
Manitou 150 AETJ-C: from PLN 220 + VAT per day
The lowest rate applies to rentals of more than 14 days; for shorter rentals the daily rate is higher. We arrange delivery across Poland.
See the price list: rates for 1–3, 7 and 14 daysAsk about availability and price Buy the rented machine: will it prove itself on the job? You can buy it from us, with the possibility of deducting part of the rental costs from the price of the machine.What are the specifications of the Manitou 150 AETJ-C?
- Working height
- 15 m
- Platform height
- 13 m
- Capacity
- 200 kg
- Horizontal outreach
- 7.6 m
- Unladen weight
- 6,700 kg
- Power source
- Electric
- Drive
- 2WD
- Tyres
- Non-marking
- Intended use
- Indoor
- Horizontal outreach
- 7.60 m
- Up-and-over height
- 7.00 m
- Platform occupants (indoor / outdoor)
- 2 / 2
- Platform dimensions
- 1.20 × 0.92 m
- Platform floor height (entry)
- 0.40 m
- Jib length
- 1.26 m
- Jib vertical articulation (up / down)
- +65° / −65°
- Jib horizontal rotation (3D version)
- +70° / −70°
- Turntable rotation
- 355°
- Platform rotation (right / left)
- 66° / 59°
- Turning radius (inside / outside)
- 1.87 m / 3.96 m
What are the dimensions of the Manitou 150 AETJ-C?
- AOverall length (transport)
- 6.05 m
- BLength with platform folded (storage position)
- 4.40 m
- COverall width
- 1.50 m
- DOverall height (transport)
- 1.97 m
- EHeight with platform folded (storage position)
- 2.08 m
- FWheelbase
- 2.00 m
- GGround clearance (chassis centre)
- 0.14 m
- R1Inside turning radius
- 1.87 m
- R2Outside turning radius
- 3.96 m
What does renting the Manitou 150 AETJ-C include?
- We arrange transportDelivery and collection of the machine: Bydgoszcz, Toruń, Poznań and all over Poland.
- Current UDT inspectionThe machine arrives after inspection, with a valid UDT inspection (UDT is the Polish Office of Technical Inspection) and full documentation.
- Mobile serviceRepair on site at the customer's location, on the construction site, in the hall or warehouse; if needed, a replacement machine from a fleet of over 250 machines.
What is the Manitou 150 AETJ-C used for?
The Manitou 150 AETJ-C is a compact electric articulating cherry picker for work in industrial buildings, warehouses and public buildings. A platform height of 13 m, 7 m of outreach over obstacles and 355° turret rotation let you service installations above production lines and racking without repositioning the chassis. The 1.20 × 0.92 m basket holds two people, and the total capacity is 200 kg.
The machine is 1.5 m wide and 1.97 m high for transport, and with the basket folded its length drops to 4.40 m (the height then rises to 2.08 m), which makes it easier to use a goods lift or pass through narrow gates. Power from 48 V / 240 Ah batteries with a built-in charger, solid non-marking tyres and a travel speed of up to 5 km/h make it ready for work on industrial floors. The unladen weight is 6,700 kg; before driving onto a floor slab, its load-bearing capacity must be checked.
Among 15 m class electric cherry pickers, the AETJ-C stands out with a very small tail swing (0.12 m with the turret rotated 90°), so it can work right next to walls and racking without the risk of the counterweight catching on them. If greater horizontal outreach is needed, we offer models in the same class with outreach of up to 9 m.
- Installations above production lines
- Work right next to walls
- Industrial building lighting maintenance
- Interiors accessed by goods lift
- Installation work in retail premises
- Maintenance in operating plants
