Haulotte · Diesel articulating boom lift
Haulotte HA16 RTJ
Diesel articulating boom lift rental · working height 16 m · capacity 230 kg · 4×4 drive
- Working height
- 16m
- Capacity
- 230kg
- Horizontal outreach
- 8.3m
- Width
- 2.3m
- Weight
- 6,095kg
The Haulotte HA16 RTJ diesel articulating boom lift, available for rental, provides 16 m of working height, 8.3 m of horizontal outreach and 230 kg of capacity for two people, making it a versatile cherry picker for construction sites and outdoor areas. It stands out for climbing gradients of up to 40%, 37 cm of ground clearance and a Stage V compliant engine. We deliver it around Bydgoszcz, Toruń, Poznań and across Poland.
Haulotte
Rental
Haulotte HA16 RTJ: from PLN 200 + VAT per day
The lowest rate applies to rentals of more than 14 days; for shorter rentals the daily rate is higher. We arrange delivery across Poland.
See the price list: rates for 1–3, 7 and 14 daysAsk about availability and price Prefer to buy? Haulotte HA16 RTJ, newBuy the rented machine: will it prove itself on the job? You can buy it from us, with the possibility of deducting part of the rental costs from the price of the machine.What are the specifications of the Haulotte HA16 RTJ?
- Working height
- 16 m
- Platform height
- 14 m
- Capacity
- 230 kg
- Horizontal outreach
- 8.3 m
- Platform occupants
- 2
- Unladen weight
- 6,095 kg
- Power source
- Diesel
- Engine type
- Diesel
- Drive
- 4WD
- Tyres
- Rough terrain
- Intended use
- Outdoor
- Up-and-over height (articulation height)
- 7.65 m
- Jib vertical articulation
- 140° (- 80° / + 60°)
- Platform rotation angle
- 165° (- 75° / + 90°)
- Turntable rotation
- 355° (non-continuous)
- Tail swing
- 10 cm
- Permissible tilt angle
- 5 °
- Drive speed
- 5.2 km/h
- Outdoor use up to a maximum wind speed of
- 45 km/h
- Maximum gradeability
- 40%
What are the dimensions of the Haulotte HA16 RTJ?
- AOverall length
- 6.75 m
- BWidth
- 2.3 m
- CHeight
- 2.3 m
- DWheelbase
- 2.1 m
- EGround clearance
- 37 cm
- FPlatform width
- 0.80 m
- GPlatform length
- 1.83 m
- HTransport length
- 5.05 m
- ITransport height
- 2.4 m
What is the Haulotte HA16 RTJ used for?
The HA16 RTJ is a rough terrain articulating aerial work platform: the lower boom raises the articulation point to a height of up to 7.65 m, and the upper boom lifts the basket floor to 14 m. The 1.83 × 0.80 m platform is designed for two people and rotates through 165°, and the vertical range of jib movement is 140°. This makes it easier to position precisely at a cornice, beam or gutter during façade, roofing and installation work.
Rough terrain tyres measuring 830 × 285 mm, 4WD and 37 cm of ground clearance let it reach work points across soft and uneven sites. Work at height is permitted in winds of up to 45 km/h, and the machine's permissible tilt is 5°. The 18.4 kW Kohler KSD 1403 engine complies with Stage V; because of its exhaust fumes, the machine is intended primarily for outdoor use.
When choosing, take its size into account: 6.75 m length, 2.3 m width and an unladen weight of 6,095 kg. The upper structure rotates through 355° (non-continuous), and the outside turning radius is 4.5 m, which matters when manoeuvring on a tight site. If continuous rotation of the upper structure is needed, consider the HA16 RTJ PRO version.
- Façade and roof renovation
- Installing outdoor services
- Work on soft construction sites
- Tree care
- Maintenance of canopies and halls
What does renting the Haulotte HA16 RTJ include?
- We arrange transportDelivery and collection of the machine: Bydgoszcz, Toruń, Poznań and all over Poland.
- Current UDT inspectionThe machine arrives after inspection, with a valid UDT inspection (UDT is the Polish Office of Technical Inspection) and full documentation.
- Mobile serviceRepair on site at the customer's location, on the construction site, in the hall or warehouse; if needed, a replacement machine from a fleet of over 250 machines.
